Netrack
Telecom Racks-NSTR 2 Series
Model No :
NSTR 2 Series
Part Code :
NSTR 2 Series

Overview

NSTR 2 Series are Available in 2200 Height with 200, 300, 400 with integrated side panel and 600, 800 and 1000 with removable side panels Depth configurations and 600 width configurations

Standard for Racks configuration will be welded frame with 4 no Pillars of 5 folded profile welded to top and bottom ribbed/reinforced frame additionally supported depth wise by welding 6 no depth rail 4 folded profile. Associated with vented top cover with fan mounting. The Racks will be Free Standing on Plinth.

Features
-Conforms to ETSI-21 Standard
-Confirms to DIN 41494 or Equivalent EIA / ISO / EN / CEA with adopter Standard adjustable mounting depth
-Numbered U positions
-State-of-the-art manufacturing methods provide the best product quality and fastest delivery in the industry
-Grounding and Bonding options
-Fan module Mount provision on top cover
-100% assured compatibility with all equipments conforming to DIN 41494 (General industrial standard for equipments) Powder coated finish with seven tank pretreatment process meeting ASTM standard
-4 No Adjustable, 21” verticals with Punched 10 mm Square Hole and Universal 25mm alternating hole pattern offers greater mounting flexibility, maximizes usable mounting space
