NETALLY EXG-200,EtherScope nXG Portable Network Expert
Model No :
EXG-200
Part Code :
EXG-200

Overview

Deploying and maintaining Wi-Fi and wired network infrastructure without the right tools can be daunting… and costly. The EtherScope nXG enables engineers and technicians to get more done faster, from deployment to maintenance and documentation of their ever-changing Wi-Fi and Ethernet access networks. With its simple operation, yet in-depth visibility, and the ability to remotely access and control EtherScope nXG, engineers can now fully enable and collaborate with “local hands” of field technicians at remote sites to expedite problem solving.

Features
- Install, test, verify, and troubleshoot technology upgrades, NBASE-T, 10G, and Wi-Fi 5/6 networks with advanced AndroidTM-based troubleshooting apps and purpose-built test hardware
- Verify up to 10G Ethernet link performance for critical servers, uplinks and key end devices, and validate Wi-Fi network performance
- Empower technicians who may not have access to network management systems or other engineer-level tools to assess and document complex network deployments with multiple VLANs and Wi-Fi SSIDs
- Seamlessly consolidate and manage field test data, and integrate with network management systems via complimentary Link-Live Cloud Service
General Specifications
- Dimensions 4.05 in x 7.67 in x 2.16 in (10.3 cm x 19.5 cm x 5.5 cm)
- Weight 1.68 lbs. (0.77 kg)
- Battery Rechargeable lithium-ion battery pack (7.2 V, 6.4 A, 46 Wh)
- Battery life Typical operating life is 3-4 hours; Typical charge time is 3 hours
- Display 5.0-inch color LCD with capacitive touchscreen (720 x 1280 pixels)
- Host Interfaces RJ-45 and SFP Analysis ports
- RJ-45 Cable Test and Management Port
- USB Type-A Port and USB Type-C On-the-Go Port
- SMA Connector (for External Directional Antenna)
- SD Card Port Supports Micro SD card storage – up to 64GB supported
- Memory Approximately 8 GB available for storing test results and user applications
- Charging USB Type-C 45-W adapter: 100-240 Vac, 50-60 Hz; DC Output Power 15 V (3 A)
- RJ-45: 802.3at PoE (25W) or higher
- Media Access Copper: 10M/100M/1G/2.5G/5G/10G
- Fiber SFP Adapters: 1G/10GBASE-X
- Supported IEEE Standards Wired: 802.3/ab/ae/an/bz/i/u/z Wi-Fi: 802.11a/b/g/n/ac
- PoE: 802.3af/at/bt, Class 0-8 and UPOE
- Cable Test Pair lengths, opens, shorts, split-pairs, crossed, straight through, and WireView ID
